FAG Ball Bearings

Bearing Model	Series Type	Bore d (mm)	Outer Dia D (mm)	Width B (mm)	Basic Dynamic Radial Load Cr (N)	Basic Static Radial Load C0r (N)	Grease Lubrication Limit Speed (min⁻¹)	Oil Lubrication Limit Speed (min⁻¹)	Reference Mass (g)	Notes
6205-2RSR	Single Row Deep Groove Ball	25	52	15	14000	7800	12000	15000	140	Double-lip seals, pressed steel cage
6308-2Z	Single Row Deep Groove Ball	40	90	23	58500	37500	8500	10500	530	Metal shields, standard design
6010-M	Single Row Deep Groove Ball	50	80	16	32000	22800	9000	11500	320	Machined brass cage, open type
4206-B-TVH	Double Row Deep Groove Ball	30	62	20	31500	20800	7500	9500	280	Reinforced nylon cage, high load
7204-C-TVP	Single Row Angular Contact Ball	20	47	14	14300	7800	13000	16500	110	15° contact angle, polyamide cage
7308-B-J	Single Row Angular Contact Ball	40	90	23	63000	47500	7500	9500	550	40° contact angle, pressed steel cage
1206-K-TVH	Self-Aligning Ball	30	62	16	15800	5000	8000	10000	210	Tapered bore, self-aligning capability
2207-2RS	Double Row Self-Aligning Ball	35	72	23	31000	10000	6500	8000	380	Sealed, double row, high misalignment tolerance
QJ308-MA	Four-Point Contact Ball	40	90	23	60000	53000	7000	9000	540	Four-point contact, combined loads
51210	Axial Deep Groove Ball	50	78	22	–	71500	4500	5800	260	Single direction thrust, pure axial load
52314	Double Direction Thrust Ball	70	125	48	–	225000	2800	3600	1250	Double direction, heavy axial load
HS7003-C-T-P4S	Super Precision Angular Contact Ball	17	35	10	6400	3200	20000	26000	60	P4S super precision, machine tool spindle
