NU 1006 HC Hybrid Ceramic Cylindrical Roller Bearing
| Parameter | Specification |
|---|---|
| Bearing Model | NU 1006 HC Hybrid Ceramic Cylindrical Roller Bearing |
| Base Model | NU1006 Cylindrical Roller Bearing |
| Structure | Single Row Cylindrical Roller, NU Type (No Inner Ring Ribs, Axially Free) |
| Inner Diameter (d) | 30 mm |
| Outer Diameter (D) | 55 mm |
| Width (B) | 13 mm |
| Roller Material | Silicon Nitride (Si3N4) Ceramic |
| Ring Material | High-Quality Bearing Steel (AISI 52100 / GCr15) |
| Cage Material | High-Temperature Resistant Steel, Brass, or PEEK (depending on speed) |
| Seal Type | Open (Standard for NU type) |
| Operating Temperature | -40°C to +1000°C (Ceramic limit) / +120°C (Steel ring grease limit) |
| Key Features | Electrically Insulating, High-Speed Capability, Low Friction, Extended Life, Lightweight Rollers |
